InSb Hall Effect Elements CYTY922B, Max. Sensitivity: 9.12 - 14.8 (mV/mT)

InSb Hall Effect Elements CYTY922B, Max. Sensitivity: 9.12 - 14.8 (mV/mT)
Quantity Unit price
until 9 € 2.56 *
from 10 € 2.13 *
from 20 € 1.77 *
from 50 € 1.48 *
from 100 € 1.24 *

Prices incl. VAT excl. Shipping Costs

Ready for shipping, delivery time 1-3 workdays

Hall-effect element CYTY922B is made of compound semiconductor material indium stibnite (InSb),... more
InSb Hall Effect Elements CYTY922B, Max. Sensitivity: 9.12 - 14.8 (mV/mT)

Hall-effect element CYTY922B is made of compound semiconductor material indium stibnite (InSb), which utilizes the Hall-effect principle. It can convert a magnetic flux density signal linearly into voltage output.

Features

  • High Magnetic Sensitivity
  • Low Offset Voltage
  • Miniature Package

Typical application

  • Magnetic Field Measurement
  • Current Sensor
  • Detection of Speed
  • DC Brushless Motor
  • Position Control
Package/Size: SIP/2.7x2.35x0.95mm
Max. Sensitivity: 9.12 ~ 14.8 mV/mT
Input/Output Resistance: 240 ~ 550kΩ/240 ~ 550kΩ
Max. Supply current/voltage: 10 mA
Operating Temperature: -40°C ~ +110°C
