AC Current Sensor CYCS11-54S2, Output: 4-20 mA DC, Power Supply: +24 V DC, Window: Ø 6,5 mm
Quantity | Unit price |
---|---|
until 4 | € 64.70 * |
from 5 | € 58.82 * |
from 10 | € 53.47 * |
Prices incl. VAT excl. Shipping Costs
Article not in stock, Delivery time 3-4 Weeks
- Article-Nr: CYCS11-54S2-0.5-5A
- Serial-Nr: CYCS11-xnS2
- Request on this Article
- Data Sheet Download
The CYCS11-xnS2 AC Current Sensor/Transducer works according electro-magnetic induction and is... more
AC Current Sensor CYCS11-54S2, Output: 4-20 mA DC, Power Supply: +24 V DC, Window: Ø 6,5 mm
The CYCS11-xnS2 AC Current Sensor/Transducer works according electro-magnetic induction and is designed for applications to measurement and monitoring of single phase AC current. The output signal (DC voltage or current) of this transducer is proportional to the average effective value (RMS) of input AC current. They are suitable for general applications such as fixed frequency voltage supplies etc.
Application
- Multi-point current sensing and control panels
- Monitor lighting elements
- Monitor heating elements
- Remote current sensing
- Monitor motor faults
Nominal Input Current: | 0-5A, 0-10A, 0-15A, 0-25A |
Output Signal: | 4-20 mA DC |
Current Type: | AC |
Window Type: | Round |
Direction: | bidirectional |
Operating Temperature: | -10°C ~ +60°C |
Power Supply: | +24 V DC |
Response Time: | ≤400ms |
Accuracy: | 0.5% |
Window Size (mm): | Ø 6,5 |
