Bidirectional DC Leakage Current Sensor CYCT04-25S40, Output: ±20 mA DC, Power Supply: ±12 V DC, Window: Ø 40 mm
| Quantity | Unit price |
|---|---|
| Until 4 |
€50.80
|
| From 5 |
€46.18
|
| From 10 |
€41.98
|
Article not in stock, delivery time 3-4 Weeks
Product information "Bidirectional DC Leakage Current Sensor CYCT04-25S40, Output: ±20 mA DC, Power Supply: ±12 V DC, Window: Ø 40 mm"
This current sensor is based on magnetic modulation principle and can be used for measurement of DC currents.
Applications:
- Isolation Monitoring of DC power systems and cable selection systems
- Isolation measurement of small DC currents and leakage currents
Product Characteristics:
- Application of Ageing Technology
- 100% Ageing Processing and Thermal Drift Test under high operating temperature in order to guarantee the long term stability of the sensors
- Custom makeable according to individual requirements
- Various current and voltage outputs are selectable
- Power supply options: +12V, +15V, +24V, ±12VDC and ±15VDC
- Sensors with window for contactless measurement
Information about product safety:
Manufacturer/ EU Responsible Person:
Company name: ChenYang Technologies GmbH & Co.KG
Address: Markt Schwabener Str. 8; 85464 Finsing; Deutschland
E-Mail: info@chenyang.de
Phone: +49 8121 2574100
| Accuracy: | 1,0% |
|---|---|
| Current Type: | DC |
| Direction: | bidirectional |
| Operating Temperature: | -25°C ~ +70°C |
| Output Signal: | ±20mADC |
| Power Supply: | ±12 V DC |
| Rated Input Current/Voltage: | 0-1A, 0-2A, 0-3A, 0-4A, 0-5A, 0-10mA, 0-20mA, 0-50mA, 0-100mA, 0-200mA, 0-500mA |
| Response Time: | ≤120ms |
| Window Size (mm): | Ø 40 |
| Window Type: | Round |
