High Accurate Hall Effect AC/DC Current Sensor CYHCS-LTHB1, Output: ±100 mA AC/DC, Power Supply: ±15 V ~ ±24 V DC, Window: Ø 35 mm, Connector: Molex

Preview: High Accurate Hall Effect AC/DC Current Sensor CYHCS-LTHB1, Output: ±100 mA AC/DC, Power Supply: ±15 V ~ ±24 V DC, Window: Ø 35 mm, Connector: Molex Preview: High Accurate Hall Effect AC/DC Current Sensor CYHCS-LTHB1, Output: ±100 mA AC/DC, Power Supply: ±15 V ~ ±24 V DC, Window: Ø 35 mm, Connector: Molex
High Accurate Hall Effect AC/DC Current Sensor CYHCS-LTHB1, Output: ±100 mA AC/DC, Power Supply: ±15 V ~ ±24 V DC, Window: Ø 35 mm, Connector: Molex
High Accurate Hall Effect AC/DC Current Sensor CYHCS-LTHB1, Output: ±100 mA AC/DC, Power Supply: ±15 V ~ ±24 V DC, Window: Ø 35 mm, Connector: Molex

Quantity Unit price
until 4 € 75.51 *
from 5 € 68.64 *
from 10 € 62.40 *

Prices incl. VAT excl. Shipping Costs

Ready for shipping, delivery time 1-3 workdays
     for quantities up to available stock of 3 pieces (3-4 weeks if more)

Nominal Input Current:

Description Technical Properties Data Sheets Product Safety Information
Description
This Hall Effect current sensor is based on closed loop compensating principle and designed with... more
Close menu
High Accurate Hall Effect AC/DC Current Sensor CYHCS-LTHB1, Output: ±100 mA AC/DC, Power Supply: ±15 V ~ ±24 V DC, Window: Ø 35 mm, Connector: Molex

This Hall Effect current sensor is based on closed loop compensating principle and designed with a high galvanic isolation between primary conductor and secondary circuit. It can be used for measurement of DC and AC current, pulse currents etc. The output of the transducer reflects the real wave of the current carrying conductor.

Product Characteristics

  • Excellent accuracy
  • Very good linearity
  • Small size and encapsulated
  • Less power consumption
  • Current overload capability

Applications

  • Photovoltaic equipment
  • General Purpose Inverters
  • AC/DC Variable Speed Drivers
  • Battery Supplied Applications
  • Uninterruptible Power Supplies (UPS)
  • Switched Mode Power Supplies



Information about product safety:

Manufacturer/ EU Responsible Person:

Company name: ChenYang Technologies GmbH & Co.KG

Address: Markt Schwabener Str. 8; 85464 Finsing; Deutschland

E-Mail: info@chenyang.de

Phone: +49 8121 2574100

Technical Properties
more
Close menu
Nominal Input Current: 0-100A, 0-200A, 0-300A
Sensor Type: Closed-Loop
Power Supply: ±15V ~ ±24V DC
Output Signal: ±100 mA AC/DC
Current Type: AC/DC
Window Type: Round
Window Size (mm): Ø 35
Direction: bidirectional
Accuracy: 0,2%
Linearity: 0.1%
Operating Temperature: -25°C ~ +85°C
Frequency Bandwith: DC ~ 150kHz
