Magnetic Field Viewer CY-MFV555, Dimensions: 50x38, Sensitivity: 5-10mT

Preview: Magnetic Field Viewer CY-MFV555, Dimensions: 50x38, Sensitivity: 5-10mT Preview: Magnetic Field Viewer CY-MFV555, Dimensions: 50x38, Sensitivity: 5-10mT
Magnetic Field Viewer CY-MFV555, Dimensions: 50x38, Sensitivity: 5-10mT
Magnetic Field Viewer CY-MFV555, Dimensions: 50x38, Sensitivity: 5-10mT

Quantity Unit price
until 4 € 6.54 *
from 5 € 5.95 *
from 10 € 5.47 *
from 20 € 5.00 *
from 50 € 4.52 *

Prices incl. VAT excl. Shipping Costs

Ready for shipping, delivery time 1-3 workdays

Description Technical Properties Data Sheets
Description
Magnetic field viewer is a common-used device for testing magnetic field distribution of magnet... more
Close menu
Magnetic Field Viewer CY-MFV555, Dimensions: 50x38, Sensitivity: 5-10mT

Magnetic field viewer is a common-used device for testing magnetic field distribution of magnet material and devices. This device is made of a special magnetic sensing film welded in a transparent card. Its main function is to view the distribution of magnetic lines and poles of permanent magnets and electromagnets etc. With the help of the viewer you can directly detect the magnet's pole numbers, distance between poles and poles' division etc. so that the magnetization can be evaluated. The magnetic field viewer is cheap, portable, and easy to use.

A magnetic sensing film detects magnetic fields between poles and also types of magnetization. When laid on a magnet or magnet system, the film turns dark at the poles while the zones between north and south appear in a lighter colour.

Technical Properties
more
Close menu
Sensitivity: 5-10mT
Dimensions: 50x38mm
Data Sheets
more
Close menu
Data sheets to download:
