Split Core AC/DC Hall Current Sensor CYHCS-C2S1, Output: 2.5 V DC ± 1.0 V AC/DC, Power Supply: +5 V DC, Window: Ø 21 mm, Connector: Molex
| Quantity | Unit price |
|---|---|
| Until 4 |
€27.95
|
| From 5 |
€25.41
|
| From 10 |
€23.11
|
Article not in stock, delivery time 3-4 Weeks
Product information "Split Core AC/DC Hall Current Sensor CYHCS-C2S1, Output: 2.5 V DC ± 1.0 V AC/DC, Power Supply: +5 V DC, Window: Ø 21 mm, Connector: Molex"
This Hall Effect current sensor can be used for measurement of DC and AC current, pulsed currents etc. The output of the transducer reflects the real wave of the current carrying conductor.
Product Characteristics
- Excellent accuracy
- Very good linearity
- Light in weight
- Less power consumption
- Window structure
- Electrically isolating the output of the transducer from the current carrying conductor
- No insertion loss
- Current overload capability
Applications
- Frequency conversion timing equipment
- Various power supply
- Uninterruptible power supplies (UPS)
- Electric welding machines
- Numerical controlled machine tools
- Electrolyzing and electroplating equipment
- Electric powered locomotive
- Microcomputer monitoring
- Electric power network monitoring
Information about product safety:
Manufacturer/ EU Responsible Person:
Company name: ChenYang Technologies GmbH & Co.KG
Address: Markt Schwabener Str. 8; 85464 Finsing; Deutschland
E-Mail: info@chenyang.de
Phone: +49 8121 2574100
| Accuracy: | 1% |
|---|---|
| Current Type: | AC/DC |
| Direction: | bidirectional |
| Frequency Bandwith: | 0Hz ~ 20kHz |
| Linearity: | 1% |
| Nominal Input Current: | 0-30A, 0-50A, 0-100A, 0-200A, 0-300A, 0-400A, 0-500A, 0-600A |
| Operating Temperature: | -25°C ~ +85°C |
| Output Signal: | +2,5 V ± 1 V AC/DC |
| Power Supply: | +5 V DC |
| Sensor Type: | Open-Loop |
| Window Size (mm): | Ø 21 |
| Window Type: | Round |
Manufacturer:
Company name: ChenYang Technologies GmbH & Co.KG
Address: Markt Schwabener Str. 8; 85464 Finsing; Deutschland
E-Mail: info@chenyang.de
Phone: +49 8121 2574100
